IPMAE9-0100A
Camera Mount Series | IPMAE9-0100A www.dahuasecurity.com IPMAE9-0100A 1200mm pole Parameter ModelIPMAE9-0100A ColorWhite Working Temperature -30 °C to +65 °C (-22 °F to 149 °F) Working Humidity10%–90% (no condensation) Material of Housing Aluminum Dimensions Φ60.0 x 1278.3 mm (Φ23.6 x 503.3 inch) (OD x H) Net Weight 4.7 kg (10.4 lb) Gross Weight 6.7 kg (14.8 lb) Mounting Vertical mount Dimensions (mm/inch) Installation Steps Step 1 Insert the damping ring and waterproof ring of cable into the bracket housing. Step 2 Cover the spherical bracket with bracket housing. Step 3 Use three M6x20 socket head cap screws to fix the bracket housing to the Camera....
Garantie: 36 mon.
Datentabelle
Verfügbarkeit: 0
LS-E-L
Tie Rod | LS-E-L www.dahuasecurity.com LS-E-L Tie Rod of Display Unit Technical Specification Model ModelLS-E-L General Dimension (WxHxD)725~1350mmx34mmx56.5mm Suitable LCD Video WallAll series Weight1kg Features： · Firm and reliable SPCC material · Adjustable length, suitable for installation and reinforcement of all series of LCD video wall on the ground and off the wall Dimensions(mm) ～（Tunable）...
Garantie: 36 mon.
Datentabelle
Verfügbarkeit: 0
PFA101
Camera Mount Series | DH-PFA101 www.dahuasecurity.com DH-PFA101 Mount Adapter Features * Aesthetic design * Material: aluminum * Mount adapter Camera Mount Series | DH-PFA101 www.dahuasecurity.com Technical Specifications Model DH-PFA101 General Material Aluminum Dimension Φ159mmx35mm (Φ6.26”x1.38”) Pipe Thread G1 1/2’’ Load Bearing 3.0kg(6.61lb) Weight 0.24kg(0.53lb) Color White Operating Temperature -40℃~+60℃(-40℉~+140℉) Humidity <90% RH Applicable Model Please see “Accessory Selection” Order Information Type Part Number Description Camera Mount DH-PFA101 Mount adapter PFA101 Mount adapter Dimensions (mm/inch) Camera Mount Series | DH-PFA101 Rev 001.001 © 2018 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com Application Package Information * Mount adapter *1...
Garantie: 36 mon.
Datentabelle
Verfügbarkeit: 101-500
PFA102
Camera Mount Series | DH-PFA102 www.dahuasecurity.com DH-PFA102 Mount Adapter Features * Aesthetic design * Material: aluminum * Mount adapter Camera Mount Series | DH-PFA102 www.dahuasecurity.com Technical Specifications Model DH-PFA102 General Material Aluminum Dimension Φ169mmx37mm (Φ6.65”x1.46”) Pipe Thread G1 1/2’’ Load Bearing 3.0kg(6.61lb) Weight 0.25kg(0.55lb) Color White Operating Temperature -40℃~+60℃(-40℉~+140℉) Humidity <90% RH Applicable Model Please see “Accessory Selection” Order Information Type Part Number Description Camera Mount DH-PFA102 Mount adapter PFA102 Mount adapter Dimensions (mm/inch) Camera Mount Series | DH-PFA102 Rev 001.001 © 2018 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com Application Package Information * Mount adapter *1...
Garantie: 36 mon.
Datentabelle
Verfügbarkeit: 11-50
PFA103
Camera Mount Series | DH-PFA103 www.dahuasecurity.com DH-PFA103 Mount Adapter Features * Aesthetic design * Material: aluminum * Hanging mount adapter Camera Mount Series | DH-PFA103 www.dahuasecurity.com Technical Specifications Model DH-PFA103 General Material Aluminum Dimension Φ133mmx37mm (Φ5.23”x1.46”) Pipe Thread G1 1/2’’ Load Bearing 3.0kg(6.61lb) Weight 0.13kg(0.29lb) Color White Operating Temperature -40℃~+60℃(-40℉~+140℉) Humidity <90% RH Applicable Model Please see “Accessory Selection” Order Information Type Part Number Description Camera Mount DH-PFA103 Mount adapter PFA103 Mount adapter Dimensions (mm/inch) Camera Mount Series | DH-PFA103 Rev 001.001 © 2018 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com Application Package Information * Mount adapter *1...
Garantie: 36 mon.
Datentabelle
Verfügbarkeit: 6-10
PFA106
Camera Mount Series | DH-PFA106 www.dahuasecurity.com DH-PFA106 Adapter Plate of Mini Dome & Eyeball Camera Features * Neat & Integrated design. * Material: Aluminum. Camera Mount Series | DH-PFA106 www.dahuasecurity.com Technical Specifications Model DH-PFA106 General Material Aluminum Dimension (W x H x D) Φ134.1mmx83.5mm(Φ5.28”x3.29”) Weight 0.29kg(0.64lb) Load Bearing 1kg(2.2lb) Color White Operating Temperature -40ºC ~60ºC(-40℉~140℉) Humidity <90% RH Applicable Model DH-PFB305W, DH-PFB220C Order Information Type Part Number Description Camera Mount Series DH-PFA106 Adapter plate _ Dahua brand PFA106 Adapter plate _Neutral, no brand DH-PFB305W Wall mount bracket _ Dahua brand PFB305W Wall mount bracket _Neutral, no brand DH-PFB220C Ceiling mount bracket _ Dahua brand DH-PFB220C Ceiling mount bracket _Neutral, no brand Dimensions (mm/inch) Camera Mount Series | DH-PFA106 Rev 001.001 © 2016 Dahua. All rights reserved. Design and specification...
Garantie: 36 mon.
Datentabelle
Verfügbarkeit: 101-500
PFA107
Camera Mount Series | DH-PFA107 www.dahuasecurity.com DH-PFA107 Adapter Plate of PT Network Camera Features * Neat & Integrated design. * Material: Aluminum. Camera Mount Series | DH-PFA107 www.dahuasecurity.com Technical Specifications Model DH-PFA107 General Material Aluminum Dimension (W x H x D) Φ134.1mmx83.5mm(Φ5.28”x3.29”) Weight 0.29kg(0.64lb) Load Bearing 1kg(2.2lb) Color White Operating Temperature -40ºC ~60ºC(-40℉~140℉) Humidity <90% RH Applicable Model DH-PFB305W, DH-PFB220C Order Information Type Part Number Description Camera Mount Series DH-PFA107 Adapter plate _ Dahua brand PFA107 Adapter plate _Neutral, no brand DH-PFB305W Wall mount bracket _ Dahua brand PFB305W Wall mount bracket _Neutral, no brand DH-PFB220C Ceiling mount bracket _ Dahua brand DH-PFB220C Ceiling mount bracket _Neutral, no brand Dimensions (mm/inch) Camera Mount Series | DH-PFA107 Rev 001.001 © 2017 Dahua. All rights reserved. Design and specifications are subject...
Garantie: 36 mon.
Datentabelle
Verfügbarkeit: 51-100
PFA110
Camera Mount Series | DH-PFA110 www.dahuasecurity.com DH-PFA110 Mount Adapter Features * Aesthetic design * Material: aluminum * Mount adapter Camera Mount Series | DH-PFA110 www.dahuasecurity.com Technical Specifications Model DH-PFA110 General Material Aluminum Dimension Φ59mmx53mm (Φ2.32”x2.09”) Pipe Thread G1 1/2’’ Load Bearing 5.0kg(11.02lb) Weight 0.2kg(0.44lb) Color White Operating Temperature -40℃~+60℃(-40℉~+140℉) Humidity <90% RH Applicable Model Please see “Accessory Selection” Order Information Type Part Number Description Camera Mount DH-PFA110 Mount adapter PFA110 Mount adapter Dimensions (mm/inch) Camera Mount Series | DH-PFA110 Rev 001.001 © 2018 Dahua. All rights reserved. Design and specifications are subject to change without notice. www.dahuasecurity.com Application Package Information * Mount adapter *1...
Garantie: 36 mon.
Datentabelle
Verfügbarkeit: 0
