DS-1273ZJ-135(Black)

DS-1273ZJ-135(Black)  Wall Mount      Features   Aluminum alloy with surface spray treatment   Internal cable routing design   Cap design facilitates installation  Dimension  120 mm (4.72" )  85.7 mm (3.37" )  183  .5  mm  (7  .22  " )  158  mm  (6  .22  " )  83.5 mm (3.29" )  46 mm (1.81" )  6-M4 Depth:  8 mm (0.31" )  83  .5  mm  (3  .29  " )  230 mm (9.06" )      Available Model  DS-1273ZJ-135(Black)  Parameter  Model    Parameters  DS-1273ZJ-135(Black)  Wall Mount  Appearance Black  Material Aluminum Alloy  Dimension 120 mm x 183.5 mm x 230 mm (4.72" x 7.22" x 9.06")  Weight 870 g (1.92 lb.)  Notes   The mount should be installed on the flat surface.   The wall must be capable of supporting at least 3 times as much as the total weight of the camera, and the  mount.   The maximum load capacity of the mount is 4.5 kg (9.9 lb.)....

Garantie: 36 mon.

Datentabelle

Textinhalt des PDF-Datenblattes:

DS-1273ZJ-135(Black)
Wall Mount


Features
 Aluminum alloy with surface spray treatment
 Internal cable routing design
 Cap design facilitates installation
Dimension
120 mm (4.72" )
85.7 mm (3.37" )
183
.5
mm
(7
.22
" )
158
mm
(6
.22
" )
83.5 mm (3.29" )
46 mm (1.81" )
6-M4 Depth:
8 mm (0.31" )
83
.5
mm
(3
.29
" )
230 mm (9.06" )


Available Model
DS-1273ZJ-135(Black)
Parameter
Model

Parameters
DS-1273ZJ-135(Black)
Wall Mount
Appearance Black
Material Aluminum Alloy
Dimension 120 mm x 183.5 mm x 230 mm (4.72" x 7.22" x 9.06")
Weight 870 g (1.92 lb.)
Notes
 The mount should be installed on the flat surface.
 The wall must be capable of supporting at least 3 times as much as the total weight of the camera, and the
mount.
 The maximum load capacity of the mount is 4.5 kg (9.9 lb.).
