DS-1273ZJ-155-Black
Wall Mount


Feature
 Alloy with surface spray treatment
 The cap facilitates the installation
 Adopts waterproof design
Dimension
83.5 mm
(3.29'')46 mm
(1.81'')
83
.5
mm
(3
.29
'')
6-M4
depth 8 mm (0.31'')
158
mm
(6
.22
'')
183
mm
(7
.20
'')
85.7 mm (3.37'')
120 mm (4.72'')
240 mm (9.45'')


Available Model
DS-1273ZJ-155-Black
Parameter
Model

Parameters
DS-1273ZJ-155-Black
Wall Mount
Appearance Hikvision Black
Material Alloy
Dimension Φ 155 mm x 183.5 mm x 240 mm (Φ 6.10" x 7.20" x 9.45")
Weight Approx. 760 g (1.68 lb.)
Note
 The mount should be installed on the flat surface.
 The wall should be capable of supporting at least 3 times as much as the total weight of the camera and the mount.
 The maximum load capacity of the mount is 3 kg (6.6 lb.).
