DS-2CE12DFT-PIRXOF28(2.8mm)

DS-2CE12DFT-PIRXOF28  2 MP PIR Siren Full Time Color Camera          • 2 MP, 1920 x 1080 resolution  • 24-hour color image  • 130 dB true WDR, 3D DNR  • 2.8 mm fixed focal lens  • Smart Light, up to 40 m white light distance  • PIR detection, strobe light alarm, alarm out/audible alarm  • Built-in siren  • 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)  • IP67        Specification    Camera  Image Sensor2 MP CMOS  Signal SystemPAL/NTSC  Resolution1920 (H) x 1080 (V)    Frame Rate  TVI: 1080p@30fps, 1080p@25fps  AHD: 1080p@30fps, 1080p@25fps  CVI: 1080p@30fps, 1080p@25fps  CVBS: PAL/NTSC    Min. illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with White Light    Shutter Time  PAL: 1/25 s to 1/50, 000 s  NTSC: 1/30 s to 1/50, 000 s    Slow ShutterMax. 16 times  Lens2.8 mm fixed lens  Field of View2.8 mm, horizontal FOV: 104°, vertical FOV: 54°, diagonal FOV: 126°  Lens MountM16  Flashing Light Alarm (Red & Blue)Yes  Audible AlarmYes  Day & NightColor  WDR (Wide Dynamic Range)≥130 dB  Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360°  Menu  White LightAuto/​Off  Image ModeSTD/HIGH-SAT  AGCYes  White BalanceAuto/M...

Warnung! Produkt aus der Produktion genommen!

Ersatzprodukt: DS-2CE12DF3T-PIRXOS(2.8mm)

Ersatzproduktcode: 300513065

Garantie: 36 mon.

Datentabelle

Textinhalt des PDF-Datenblattes:

DS-2CE12DFT-PIRXOF28
2 MP PIR Siren Full Time Color Camera




• 2 MP, 1920 x 1080 resolution
• 24-hour color image
• 130 dB true WDR, 3D DNR
• 2.8 mm fixed focal lens
• Smart Light, up to 40 m white light distance
• PIR detection, strobe light alarm, alarm out/audible alarm
• Built-in siren
• 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
• IP67



Specification

Camera
Image Sensor2 MP CMOS
Signal SystemPAL/NTSC
Resolution1920 (H) x 1080 (V)

Frame Rate
TVI: 1080p@30fps, 1080p@25fps
AHD: 1080p@30fps, 1080p@25fps
CVI: 1080p@30fps, 1080p@25fps
CVBS: PAL/NTSC

Min. illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with White Light

Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s

Slow ShutterMax. 16 times
Lens2.8 mm fixed lens
Field of View2.8 mm, horizontal FOV: 104°, vertical FOV: 54°, diagonal FOV: 126°
Lens MountM16
Flashing Light Alarm (Red & Blue)Yes
Audible AlarmYes
Day & NightColor
WDR (Wide Dynamic Range)≥130 dB
Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360°
Menu
White LightAuto/​Off
Image ModeSTD/HIGH-SAT
AGCYes
White BalanceAuto/Manual
AE (Auto Exposure) ModeWDR/BLC/HLC/Global/HLS
Anti-​BandingYes
Privacy Mask4 programmable privacy masks
Motion Detection4 programmable motion areas
Noise Reduction3D DNR/ 2D DNR
LanguageEnglish
FunctionBrightness, Sharpness, Mirror, Smart Light, Defective Pixel Correction
Interface
Video OutputSwitchable TVI/AHD/CVI/CVBS
Alarm1 alarm out


General
Operating Conditions-40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing)

Power Supply
12 VDC ± 25%
*You are recommended to use one power adapter to supply the power for one camera.

Power ConsumptionMax. 8.5 W
Protection LevelIP67

Material
Front Cover: Metal
Main Body: Plastic

White Light RangeUp to 40 m
PIR RangeAngle: 110°, Range: 11 m
CommunicationHIKVISION-C
Dimensions77.1 mm x 82.6 mm x 208.9 mm (3.04" x 3.25" x 8.22")
WeightApprox. 441 g ( 0.97 lb.)

Available Model
DS-2CE12DFT-PIRXOF28
Dimension

Accessory



DS-1280ZJ-XS
Junction Box
