Warnung! Produkt aus der Produktion genommen!

Garantie: 36 mon.

Datentabelle

Textinhalt des PDF-Datenblattes:

DS -7200HGHI -SH SERIES TURBO HD DVR
Video Input and Transmission
 Connectable to HDTVI and analog cameras
 Up to 2-ch 1080p IP cameras input for DS-7208/7216HGHI-SH
 Long distance transmission over UTP and coaxial cable
Compression and Recording
 Full channel recording at up to 1080p resolution
Video Output
 Simultaneous HDMI/VGA output at up to 1920x1080 resolution
Storage and Playback
 Two SATA interfaces (up to 6 TB capacity per HDD) for DS-7208/7216HQHI-SH
 4/8/16 -ch synchronous playback at up to 108 0p resolution
 Smart search for efficient playback
Smart Function
 Supports mu ltiple VCA (Video Content Analytics) events for both analog and smart IP cameras
 VQD (Video Quality Diagnostics)
Network & Ethernet Access
 Hik Cloud P2P & HiDDNS (Dynamic Domain Name System) for easy network management
 1 gigabit Ethernet network interface for DS -7216HGHI-SH

Features and Functions







Model

DS -7204HGHI-SH DS -7208HGHI-SH DS -7216HGHI-SH
Video/Audio
input
Video compression H.264
Analog and HDTVI video
input
4-ch 8-ch 16 -ch
BNC interface (1.0 Vp -p, 75 Ω), supporting coaxitron connection
Supported camera types 720 p25, 720p30, 720p50, 720p60, 1080p25, 1080 p30, CVBS
IP video input
1-ch 2-ch
Up to 1080p resolution
Audio compression G.711u
Audio input/Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
HDMI/VGA output
1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x
768/60 Hz
Encoding resolution 1080p/720p/VGA/WD1/4CIF/CIF
Frame rate
Main stream:
1080p@12fps;
720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps;
CIF/QCIF/QVGA@25fps (P)/30fps (N)
Video bit rate 32 Kbps to 6 Mbps
Audio output 1-ch, RCA (Linear, 1 KΩ)
Audio bit rate 64 Kbps
Dual stream Support
Stream type Video, Video & Audio
Synchronous playback 4-ch 8-ch 16 -ch
Network
management
Remote connections 128
Network protocols
TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP,
SNMP, NFS, iSCSI, UPnP™, HTTPS
Hard disk
SATA 1 SATA interface 2 SATA interfaces
Capacity Up to 6 TB capacity for each disk
External
interface
Network interface
1, 10M/100M self -adaptive Ethernet
interface
1, 10M/100M/1000M
self-adaptive Ethernet
interface
Serial interface RS-485 (half-duplex)
USB interface 2 x USB 2.0
General
Power supply 12 VDC
Consumption
(without HDD )
≤ 15 W ≤ 20 W ≤ 30 W
Working temperature -10 ºC to +55 ºC (14 ºF to 131 ºF)
Working humidity 10% to 90%
Dimensions
(W x D x H)
315 x 242 x 45 mm (12.4 x 9.5 x 1.8 inch)
380 x 290 x 48 mm
(15.0 x 11.4 x 1.9
inch)
Weight
(without HDD )
≤ 1.5 kg (3.3 lb) ≤ 2 kg (4.4 lb)
Specifications




Index Description Index Description
1 VIDEO IN 7 LAN Network Interface
2 AUDIO IN, RCA Connector 8 RS-485 Serial Interface
3 AUDIO OUT, RCA Connector 9 12 VDC Power Input
4 VGA Interface 10 Power Switch
5 HDMI Interface 11 GND
6 USB Interface
DS -7204HGHI-SH, DS-7208HGHI-SH , DS -7216HGHI-SH

Physical Interfaces
030 3031061122
Available Models
The rear panel of DS-7204/7216HGHI-SH provides 4/16 video input interfaces.
