Hikvision USA Inc., 908 Canada Court, City of Industry, CA 91748, USA • Hikvision Canada, 4485 Dobrin, St-Laurent, Quebec, Canada, H4R 2L8
Tel: +1-909-895-0400 • Toll Free in USA: +1-866-200-6690 • E-Mail: sales.usa@hikvision.com • www.hikvision.com
© 2016 Hikvision USA Inc. • All Rights Reserved • Specifications subject to change without notice. 102116NA
DS-7332HGHI-SH
TurboHD DVR




Key Features
• Dual Stream H.264 Compression
• HD-TVI/Analog/Network Camera Tribrid
• Auto-Detect/Configure HD-TVI/Analog Input
• Full Channel @ 1080p Resolution Non Real-Time Recording
• HDMI and VGA Output at Up to 1920 x 1080p Resolution
• High Resolution Over Coax Cable
• Supports Up to 16-ch Synchronous Playback at 1080p
Resolution
Rear Panel
1. Video In
2. Not Used
3. Audio In RCA Connectors
4. USB Port
5. HDMI
6. VGA Interface
7. VGA Audio Out
8. LAN Network Interface
9. RS-485 Serial Interface, Keyboard Interface, Alarm In
10. 100 to 240 VAC Power Input
11. Power Switch
12. GND
13. Line In
14. eSATA Interface
15. RS-232 Serial Port


DS-7332HGHI-SH
Video/Audio Input
Video Compression H.264
Analog and HD-TVI
Video Input
32-ch
BNC interface (1.0 Vp-p, 75 Ω)
Supported Camera Types
720p25, 720p30, 720p50, 720p60, 1080p25,
1080p30, CVBS
IP Video Input 8-ch (up to 32-ch)
Up to 2 MP resolution
Audio Compression G711u
Audio Input 4-ch, RCS (2.0 Vp-p, 1 K Ω)
Two-Way Audio In 1-ch, RCA (2.0 Vp-p, 1 K Ω)
Video/Audio Output
HDMI/VGA Output
1920 x 1080/60 Hz, 1280 x 1024/60 Hz, 1280 x
720/60 Hz, 1024 x 768/60 Hz
Encoding Resolution
Main stream: 1080p (non-real-time)/720p/VGA/4CIF/CIF
Sub-stream: WD1 (non-real-time)/4CIF
(non-real-time)/CIF/QCIF/QVGA
Frame Rate
Main stream: 30 fps (maximum)
Sub-stream: 30 fps (maximum)
Video Bit Rate 32 Kbps to 8 Mbps
Audio Output
2-ch, RCA (linear, 1 K Ω, for VGA output and CVBS
output respectively)
Audio Bit Rate 64 Kbps
Dual-Stream Supported
Stream Type Video, video and audio
Synchronous Playback 16-ch
Playback Resolution 1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF
Network Management
Remote Connections 128
Network Protocols
TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP,
SMTP, SNMP, NFS, ISCSI, UPnP™, HTTPS
Hard Disk
Type 4 SATA interfaces for 4 HDDs; 1 eSATA interface
Capacity Up to 6 TB capacity for each disk
External Interface
Network Interface 1; 10M/100M/1000M self-adaptive Ethernet interface
Serial Interface RS-232, RS-485, keyboard
Alarm In/Out 16/4
USB Port 3 x USB 2.0
General
Power Supply 100 to 240 VAC, 47 to 63 Hz
Consumption (w/o hard
disks)
≤65 W
Working Temperature -10° C to +55° C (14° F to 131° F)
Working Humidity 10% to 90%
Chassis 19-inch rack-mounted 1.5U chassis
Dimensions (w x d x h) 445 mm x 390 mm x 70 mm (17.5" x 15.3" x 2.7")
Weight (w/o hard disks) ≤5 Kg (11.0 lb)
Order Model
DS-7332HGHI-SH
