DS-K4T100
product unavailable
zur Wunschliste hinzufügenBeschreibung
Spec of DS-K4T100-UX Series Accessories of Electric Bolt www.hikvision.com 1 The bracket is made up of aluminum alloy It is suitable for fully frameless glass door; The door opens both sides at the angle of 180°; The thickness of the glass is 10~15mm (0.39~0.59"); The weight of the product is 0.27kg (0.60lb) DS-K4T100-UX Series DS-K4T100-U1 Lower U-bracket of Electric Bolt, for Using with DS-K4T100 Accessories of Electric Bolt DS-K4T100-U1 Installation and Dimension Spec of DS-K4T100-UX Series Accessories of Electric Bolt www.hikvision.com 2 The bracket is made up of aluminum alloy; The dimension (LxWxH) of the bracket is: 205x58x46mm (8.07x2.28x1.81") It is suitable for fully frameless glass door; The door opens both sides at angle of 180°; The thickness of the glass is 10~15mm (0.39~0.59"); The weight of the product is 1.3kg.(2.87lb) DS-K4T100-U2 Upper and lower U-bracket of Elect...
Garantie: 24 mon.
Datentabelle
Textinhalt des PDF-Datenblattes:
Spec of DS-K4T100-UX Series Accessories of Electric Bolt www.hikvision.com
1
The bracket is made up of aluminum alloy
It is suitable for fully frameless glass door;
The door opens both sides at the angle of 180°;
The thickness of the glass is 10~15mm (0.39~0.59");
The weight of the product is 0.27kg (0.60lb)
DS-K4T100-UX Series
DS-K4T100-U1
Lower U-bracket of Electric Bolt, for Using with DS-K4T100
Accessories of Electric Bolt
DS-K4T100-U1
Installation and Dimension
Spec of DS-K4T100-UX Series Accessories of Electric Bolt www.hikvision.com
2
The bracket is made up of aluminum alloy;
The dimension (LxWxH) of the bracket is:
205x58x46mm (8.07x2.28x1.81")
It is suitable for fully frameless glass door;
The door opens both sides at angle of 180°;
The thickness of the glass is 10~15mm (0.39~0.59");
The weight of the product is 1.3kg.(2.87lb)
DS-K4T100-U2
Upper and lower U-bracket of Electric Bolt, for Using with DS-K4T100
DS-K4T100-U1
Installation
