DS-KB6003-WIP

DS-KB6003-WIP  Wi-Fi Doorbell    Key Features  Basic Functions   Video intercom function, supporting the audiovisual communication  with the mobile App directly   Self-adaptive IR supplement with max. 5-meter IR distance   High-performance embedded SOC processor   IP 54 standard  Video/Audio Functions   HD video surveillance with ultra-wide angle (180º) and high performance CMOS, up to 1080P   Noise suppression and echo cancellation   H.264 video compression standard   Low illumination   Supports voice prompt   Volume configuration via App  Other Functions   Online upgrade via the mobile App   Supports motion detection and video recording   Supports the storage and playback via TF card   Equipped with a backlit call button   Equipped with a replaceable faceplate   Supports connecting to the mechanical chime   Equipped with a reset button                Model DS-KB6003-WIP  System  parameters  Processor High-Performance Embedded SOC Processor  Operation system Embedded Linux Operation System  Camera  parameters  Image sensor CMOS 2MP HD Colorful Camera  Light sensitivity Low Illumination  Lens f1.96 m...

Warnung! Produkt aus der Produktion genommen!

Garantie: 24 mon.

Datentabelle

Textinhalt des PDF-Datenblattes:

DS-KB6003-WIP
Wi-Fi Doorbell

Key Features
Basic Functions
 Video intercom function, supporting the audiovisual communication
with the mobile App directly
 Self-adaptive IR supplement with max. 5-meter IR distance
 High-performance embedded SOC processor
 IP 54 standard
Video/Audio Functions
 HD video surveillance with ultra-wide angle (180º) and high performance CMOS, up to 1080P
 Noise suppression and echo cancellation
 H.264 video compression standard
 Low illumination
 Supports voice prompt
 Volume configuration via App
Other Functions
 Online upgrade via the mobile App
 Supports motion detection and video recording
 Supports the storage and playback via TF card
 Equipped with a backlit call button
 Equipped with a replaceable faceplate
 Supports connecting to the mechanical chime
 Equipped with a reset button







Model DS-KB6003-WIP
System
parameters
Processor High-Performance Embedded SOC Processor
Operation system Embedded Linux Operation System
Camera
parameters
Image sensor CMOS 2MP HD Colorful Camera
Light sensitivity Low Illumination
Lens f1.96 mm, F 2.2
Field of view 180º (Horizontal), 96º (Vertical)
Video
parameters
Video compression
standard
H.264
Video streaming
Dual Stream
Main Stream: 1080P, Sub-Stream: VGA
Anti-flicker
frequency
50 Hz, 60 Hz
Wide dynamic range WDR
Audio
parameters
Audio streaming Two-Way, Full Duplex
Audio input Built-in Omnidirectional Microphone
Audio output Built-in Loudspeaker
Audio compression
standard
G.711 U
Audio compression
rate
64 Kbps
Audio quality Noise Suppression and Echo Cancellation
Light
supplement
Light supplement
mode
IR Supplement, IR Distance: 5 Meters
Wavelength 940 nm
Network
parameters
Network protocol TCP/IP, RTSP
Network interface 1 Wireless Interface (Wireless Network Card), Supporting 2.4 GHz
Event Motion Detection Supported
Alarm
Motion Detection
Alarm Supported
Device
interfaces
TF card Max. 128 G
Button 1 Call Button, 1 Reset Button
General
Ingress protection
level IP 54
Power supply 16 VAC to 24 VAC
Power frequency 50 Hz to 60 Hz
Power consumption Max. 12 W
Working
temperature -30° C to +50° C (-22° F to 122° F)
Working humidity 10% to 90%
Dimensions 122.4 mm x 45.9 mm x 28.1 mm (4.82" x 1.81" x 1.11")
Specifications





Available Model

Draft 0104061070216
Typical Application
DS-KB6003-WIP

Mobile App
Wi-Fi Doorbell
Mechanical Chime (Optional)
Transformer
Mains Electricity

16 VAC
to 24 VAC
Power Cable
Wi-Fi

Internet

0104061070410
