DS-KH6320-WTE2
Indoor Station



Key Feature
• Two-pin wire for power supply and network access
• UI V2.0: User friendly design
• 7-inch colorful touch screen with resolution 1024 x 600
• 2-ch transmission plan
• Stores messages and captured pictures in the TF card
• Remote unlocking via the client software or the mobile client
• Views live videos of door stations and linked cameras
• Supports wireless network
Specification

ModelDS-KH6320-WTE2

System
Processor basic frequency1 G
Memory128 MB
Flash16 MB (32 MB hardware compatibility)
Operation systemEmbedded Linux operation system

Display
Display screen7-inch TFT LCD
Display resolution1024 x 600
Operation methodCapacitive touch

Audio
Audio InputBuild-in omnidirectional microphone
Audio outputBuilt-in loudspeaker
VolumeLocal or software control


ModelDS-KH6320-WTE2
Audio compression standardG.711 U
Audio compression rate64 Kbps

Audio quality
Noise suppression and echo
cancellation

Network
Wired networkBroadR-Reach
Wireless networkWi-Fi 802.11b/g/n
ProtocolTCP/IP, SIP, RTSP

Interface
Network interfaceTwo-wire interface
RS-4851
Alarm input8 zones alarm input
Relay output2
TF cardSupport, Max. 32 GB
Power interfaceTwo-wire interface

Extended Application
Mobile clientSupport
Indoor call elevatorSupport
IPCSupport

General
Power supply modeTwo-wire
Power consumption≤ 6 W
Working temperature-10 °C to 50 °C (-14 °F to 122 °F)
Working humdity0% to 90%

Dimensions (W x H x D)
200 mm x 140 mm x 15.1 mm (7.87" x
5.51" x 0.59")

Typical Application


Available Model
DS-KH6320-WTE2
Physical Interface

No.Description
1Display Screen
2Microphone
3Alarm Terminal
4Power Interface
5Loudspeaker
6Network Interface and Power Supply
