NVR2108-8P-4KS2

Verfügbarkeit: 0
Preis: 286,28 € 286.28
bez 23.00% VAT i kosztów dostawy
quantity szt.

product unavailable

zur Wunschliste hinzufügen
Anbieter: DAHUA
Produkt-Code/SKU: NVR2108-8P-4KS2

Beschreibung

Lite series | DHI-NVR2108-8P-S2     System Overview  Dahua's NVR2000-S2 is one of the NVRs which have the most reasonable  price and best quality for IP video surveillance applications. This Lite  series NVR provides up to 6MP resolution. It supports smart H.264  decoding, save up to 70% HDD space and storage. Additionally, the NVR  features a mouse shortcut operation menu, remote management and  control, centre storage, edge storage, and back up storage.  Designed as a low-cost, easy installation, this NVR is ideal for a wide  range of applications such as home safety, grocery, wharehouse,  education, and financial institutions.  The NVR is compatible with numerous third-party devices making it  the perfect solution for surveillance systems with or without a video  management system (VMS). Its open architecture supports multi-user  access and is compatible with ONVIF 2.4, enabling interoperability when  combined with IP cameras.   Functions  Smart H.264+  Delivering high quality video without straining the network, Smart H.264+  is the optimized implementation of H.264. The Smart H.264+ encoding  platform includes a scene adaptive encoding strategy, dynamic GOP,  dynamic ROI, flexible m...

Warnung! Produkt aus der Produktion genommen!

Ersatzprodukt: NVR2108HS-8P-4KS2

Garantie: 36 mon.

Datentabelle PDF


Textinhalt des PDF-Datenblattes:

Lite series | DHI-NVR2108-8P-S2

System Overview
Dahua's NVR2000-S2 is one of the NVRs which have the most reasonable
price and best quality for IP video surveillance applications. This Lite
series NVR provides up to 6MP resolution. It supports smart H.264
decoding, save up to 70% HDD space and storage. Additionally, the NVR
features a mouse shortcut operation menu, remote management and
control, centre storage, edge storage, and back up storage.
Designed as a low-cost, easy installation, this NVR is ideal for a wide
range of applications such as home safety, grocery, wharehouse,
education, and financial institutions.
The NVR is compatible with numerous third-party devices making it
the perfect solution for surveillance systems with or without a video
management system (VMS). Its open architecture supports multi-user
access and is compatible with ONVIF 2.4, enabling interoperability when
combined with IP cameras.
Functions
Smart H.264+
Delivering high quality video without straining the network, Smart H.264+
is the optimized implementation of H.264. The Smart H.264+ encoding
platform includes a scene adaptive encoding strategy, dynamic GOP,
dynamic ROI, flexible multi-frame reference structure and intelligent noise
reduction, providing a savings of up to 70% of bandwidth and storage
when compared with standard H.264.
Plug & Play
With the Smart Add function, the installation of IP system is as easy as an
analog system, no matter the NVR with or without a PoE switch embedded.
It should be noted that the NVR has to be in the same router as cameras.
ANR (Automatic Network Replenishment Technology)
Video record in SD card in IP cameras when the network breaks down, and
after the network recovered, the video will be transferred to NVR and then
recorded in it.
Easy4ip
You can monitor at anytime and anywhere with Easy4ip. There are two
modes Easy4ip web client and mobile app. With this function, you can
manage your devices more convenient.
www.dahuasecurity.com

· H.264+/H.264 codec decoding
· Max 80Mbps incoming bandwidth
· Up to 6Mp resolution preview&playback
· HDMI/VGA simultaneous video output
· Support IPC UPnP, 8PoE ports
· 3D intelligent positioning with Dahua PTZ camera
DHI-NVR2108-8P-S2
8 Channel Smart 1U 8PoE Lite Network Video Recorder

Dual
Core
Processor

Series
Lite
6Mp

H.264
+


www.dahuasecurity.com
Lite Series | DHI-NVR2108-8P-S2

Technical Specification
System
Main ProcessorDual-core embedded processor
Operating System
Embedded LINUX
Audio and Video
IP Camera Input8 Channel
Two-way Talk1 Channel Input, 1 Channel Output, RCA
Display
Interface1 HDMI, 1 VGA
Resolution1920x1080, 1280x1024, 1280x720, 1024x768
Multi-screen Display1/4/8/9
OSD
Camera title, Time, Camera lock, Motion detection,
Recording
Recording
CompressionH.264+/H.264
Resolution6Mp/5Mp/4Mp/3Mp/1080P/ 720P/ D1&etc.
Record Rate80Mbps
Bit Rate16Kbps ~ 20Mbps Per Channel
Record ModeManual, Schedule(Regular(Continuous), MD, Stop
Record Interval
1~120 min (default: 60 min), Pre-record: 1~30 sec,
Post-record: 10~300 sec
Video Detection and Alarm
Trigger Events
Recording, PTZ, Tour, Video Push, Snapshot, and
Screen Tips
Video Detection
Motion Detection, MD Zones: 396 (22 x 18),
and Tampering
Alarm inputN/A
Relay OutputN/A
Playback and Backup
Sync Playback1/4/8
Search Mode
Time /Date, MD and Exact Search
(accurate to second)
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next
File, Previous File, Next Camera, Previous Camera,
Full Screen, Repeat, Shuffle, Backup Selection,
Digital Zoom
Backup ModeUSB Device/Network


Third-party Support
Third-party Support
Dahua, Arecont Vision, AXIS, Bosch, Brickcom,
Canon, CP Plus, Dynacolor, Honeywell, Panasonic,
Pelco, Samsung, Sanyo, Sony, Videotec, and more
Network
Interface1 RJ-45 port (10/100Mbps)
Ethernet Port1 Independent 100Mbps Ethernet Port
PoE8 ports (IEEE802.3at/af)
Network Function
HTTP, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS,
IP Filter, DDNS, IP Search(Support Dahua IP camera,
DVR, NVS and etc.), Easy4ip
Optical Fiber InterfaceN/A
Max. User Access128 users
Smart PhoneiPhone, iPad, Android
InteroperabilityONVIF 2.4, CGI Conformant
Storage
Internal HDD1 SATA III Port, up to 6TB capacity for each HDD
HDD ModeSingle
eSATAN/A
Auxiliary Interface
USB2 ports (2 Rear USB2.0)
RS232N/A
RS485N/A
Electrical
Power SupplySingle, DC48V/2A
Power Consumption<4.5W (without HDD)
Environmental
Operating Conditions-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
Storage Conditions-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
Dimensions(WxDxH)
Smart 1U, 270mmx204.7mmx45.7mm
(10.6" x 8.1" x 1.8")
Net Weight0.65kg (1.43 lb) (without HDD)
Gross Weight1.8kg(3.97 lb)(without HDD)
Certifications
CEEN55032, EN55024, EN50130-4, EN60950-1
FCCPart 15 Subpart B, ANSI C63.4-2014

Lite Series | DHI-NVR2108-8P-S2
Rev 001.001© 2016 Dahua . All rights reserved. Design and specifications are subject to change without notice

Ordering Information
TypePart NumberDescription
8 Channel NVR DHI-NVR2108-8P-S2
8 Channel Smart 1U 8PoE Lite
Network Video Recorder
Accessories N/AN/A
www.dahuasecurity.com

Dimensions (mm)
