PFS3106-4P-60
product unavailable
zur Wunschliste hinzufügenBeschreibung
DH-PFS3106-4P-60 www.dahuasecurity.com Features · Two-layer industrial PoE switch · MAC auto study and aging, MAC address list capacity is 8K · Support IEEE802.3af, IEEE802.3at standard · Conform IEEE802.3, IEEE802.3u, IEEE802.3ab/z and IEEE802.3X standards · Industrial wide temperature design DH-PFS3106-4P-60 4-Port PoE Switch (Unmanaged) Technical Specification ModelDH-PFS3106-4P-60 Ethernet Port 1*100/1000 Base-X 1*10/100/1000 Base-T 4*10/100 Base-T (PoE power supply) PoE Power ConsumptionEach power ≤30W, Total≤60W PoE ProtocolIEEE802.3af, IEEE802.3at Switching Capacity6.8G Packet Forwarding Rate3.57Mpps Packet Buffer Memory1Mb MAC Table Size8K Flow ControlEnable by default Application Humidity10%~90% PowerDC48~57V Lightning Protection Common Mode 4KV Differential Mode 2KV Working Temperature-30°C~65°C Weight480g Dimension(WxDxH)150mmx100mmx30mm Accessories Model PFT3900155M 850nm,2km,LC, Multi-mode PFT39501.25G 850nm,500m,LC, Multi-mode PFT3910155M 1310/1550nm,20km,LC, Single-mode PFT3920155M 1550/1310nm,20km,LC, Single-mode PFT39601.25G 1310/1550nm,20km,LC, Single-mode PFT39701.25G 1550/1310nm,20...
Warnung! Produkt aus der Produktion genommen!
Garantie: 36 mon.
Datentabelle
Textinhalt des PDF-Datenblattes:
DH-PFS3106-4P-60
www.dahuasecurity.com
Features
· Two-layer industrial PoE switch
· MAC auto study and aging, MAC address list capacity is 8K
· Support IEEE802.3af, IEEE802.3at standard
· Conform IEEE802.3, IEEE802.3u, IEEE802.3ab/z and
IEEE802.3X standards
· Industrial wide temperature design
DH-PFS3106-4P-60
4-Port PoE Switch (Unmanaged)
Technical Specification
ModelDH-PFS3106-4P-60
Ethernet Port
1*100/1000 Base-X
1*10/100/1000 Base-T
4*10/100 Base-T (PoE power supply)
PoE Power ConsumptionEach power ≤30W, Total≤60W
PoE ProtocolIEEE802.3af, IEEE802.3at
Switching Capacity6.8G
Packet Forwarding Rate3.57Mpps
Packet Buffer Memory1Mb
MAC Table Size8K
Flow ControlEnable by default
Application Humidity10%~90%
PowerDC48~57V
Lightning Protection
Common Mode 4KV
Differential Mode 2KV
Working Temperature-30°C~65°C
Weight480g
Dimension(WxDxH)150mmx100mmx30mm
Accessories
Model
PFT3900155M 850nm,2km,LC, Multi-mode
PFT39501.25G 850nm,500m,LC, Multi-mode
PFT3910155M 1310/1550nm,20km,LC, Single-mode
PFT3920155M 1550/1310nm,20km,LC, Single-mode
PFT39601.25G 1310/1550nm,20km,LC, Single-mode
PFT39701.25G 1550/1310nm,20km,LC, Single-mode
